Self-built automatic stamping production line

In recent years, the tendency of steel mills to seek self-built automated stamping production has become stronger and stronger. The advantages of this automation are becoming more and more apparent as it offers greater efficiency, precision and cost-effectiveness.Fanty Machinery Company has emerged as a leading supplier to meet the diverse needs of these factories by providing tailor-made automated production lines. With expertise in the field, Fanty Machinery Company understands the unique requirements of each plant and designs cutting-edge solutions that perfectly align with their production goals. By providing reliable and adaptable automated production lines, Fanty Machinery Company enables factories to increase productivity, streamline operations a

Two arms tell the flexible production line

Main Features

  • Continuous operation mode (synchronous control)
  • Good workpiece formability and long mold life
  • Production capacity reaches 15 times/minute
  • Programmable motion axes with high feeding flexibility
  • Direct transmission from press to press parts
  • Horizontal bar type mechanical feeding structure, high transmission speed,and stable transmission
  • Fully automatic mold change
  • Fully automatic replacement of end pickup
  • Compact design with small footprint
  • Modular design for easy maintenance and upkeep
  • There are special requirements for the structure of the press
  • Transmission distance: 5- 7m

Production Line Composition

Production line head unit

  • Stacking trolley (2 units)
  • Magnetic separation device
  • High speed truss destacking manipulator
  • Feeding belt conveyor
  • Cleaning machine oiling machine
  • Centering platform

Press and conveyor unit

  • 4-5 press machines
  • Double arm high- speed conveyor structure for loading, conveying, and unloading

Tail unit of production line

  • Discharge belt conveyor
  • Inspection table
  • lighting

Two arms tell the flexible production line

Main Features

  • Intermittent/continuous operation mode
  • In continuous mode, the workpiece has good formability and long mold life
  • Generating ability reaches 12 times/minute
  • Programmable for each operating axis
  • Direct transmission from press to press parts
  • High transmission speed and smooth transmission
  • Fully automatic mold change
  • Compact design with small footprint
  • Modular design for easy maintenance and upkeep
  • There are no special requirements for the structure of the press
  • Transmission distance 6-10m

Production Line Composition

Production line head unit

  • Stacking trolley (2 units)
  • Magnetic separation device
  • High speed truss destacking manipulator
  • Feeding belt conveyor
  • Cleaning machine oiling machine
  • Centering platform

Press and conveyor unit

  • 4-5 press machines
  • Double arm high- speed conveyor structure for loading, conveying, and unloading

Tail unit of production line

  • Discharge belt conveyor
  • Inspection table
  • lighting

Robot stamping production line

Main Features

  • Intermittent operation mode
  • High flexibilit, flexible programming
  • Six/Seven Axis Standard Robot
  • Direct transmission from press to press parts
  • Fully automatic mold change
  • Can achieve automatic replacement of end effectors
  • Modular design for easy maintenance and upkeep
  • There are no special requirements for the structure of the press
  • Transmission distance 6- 7.5m
  • Upgrade and transform the automation system suitable for existingstamping lines at the same time

Production Line Composition

Production line head unit

  • Stacking trolley (2 units)
  • Magnetic separation device
  • High speed truss destacking manipulator
  • Feeding belt conveyor
  • Cleaning machine oiling machine
  • Centering platform
  • Feeding manipulator/transfer

Production line head unit

  • 4-5 press machines
  • Double arm high- speed conveyor structure for loading, conveying, and unloading

Press and conveyor unit

  • Manipulator/transfer between press machines
  • Press
  • Heading press (multi link)
  • Subsequent presses (3~5 pcs eccentric type press)
  • Double arm high-speed conveyor structure for loading, conveying, and unloading

Tail unit of production line

  • Discharge belt conveyor
  • Inspection table
  • lighting

Multi station composite production line for coil material

Main Features

  • Diversified production models
  • Can adapt to the production of multiple varieties of products
  • Maximize the activation rate of equipment
  • Automatic switching of material stacks without stopping the machine
  • One click automatic folding of the transfer crossbar
  • Modular design for easy maintenance and upkeep
  • Save labor and reduce costs
  • Improve production efficiency and stability of product quality

Production Line Composition

  • Coil car
  • Uncoiling mechanism
  • Feeding device
  • Leveling device
  • Fixed length feeding
  • Material head shearing device
  • CNC oiling device
  • Dual station destacking mechanism
  • Chip shuttle positioning mechanism
  • Three dimensional double crossbar drive mechanism
  • Multi station press
  • Stamping mold
  • Product output mechanism
  • Product sorting table
  • Whole line safety protection
  • Whole line control system

Production Line Composition

  • Roll material:
    Uncoiling → Leveling→ Fixed length feeding→ First station blanking and stamping → Double crossbar sequential conveying and stamping → Product output
  • Sheet material:
    Uncoiling → Leveling →Fixed length feeding→ Progressive die stamping→ Product output

Progressive die production line

Features

  • spcaol dseged lor pgogse coinmuw mold poucton
  • High degree of automation
  • Small footprint
  • One cick start, flly automatic teding

Production Line Composition

  • Coil car
  • Uncoiling mechanism
  • Feeding mechanism
  • Leveling mechanism
  • Fixed length feeding mechanism
  • Cutting mechanism
  • Oiling device
  • Tailing feed device

Uncoiling and cutting production line

Features

  • High production efficiency
  • High degree of automation
  • Magnetic stacking
  • Two stacking modes: start stop and continuous
  • It can achieve the cuting and stacking of various shaped parts
  • Dedicated blanking press with high rigidit and precision

Production Line Composition

  • Uncoiler
  • Servo feeding
  • Feeding device
  • Telescopic platform
  • Material head shear
  • Blanking press, telescopic belt
  • Cleaning machine
  • Magnetic stacking
  • Leveling machine
  • Inspection bench
  • Adjusting ring
  • Configuration:
    High speed shearing machine/flying shear machine/swinging shear machine, can form an uncoiling shear machine (flying shear line, swinging shear line)

High strength steel progressive production line

Features

  • High production efficiency
  • High degree of automation
  • Suitable for both blanking and progressive die production
  • Automatic switching of stacking by two trucks
  • Stacking of regular and irregular pieces
  • High security

Production Line Composition

  • Coil car
  • Uncoiling mechanism
  • Feeding mechanism
  • Leveling mechanism
  • Fixed length feeding mechanism
  • Hunger and Institution
  • Oiling device
  • Tailing feed device
  • Fully automatic telescopic belt conveyor
  • Fully automatic duplex stacker

Uncoiling and cutting production line

Features

  • High production efficiency
  • High degree of automation
  • Magnetic stacking
  • Two stacking modes: start stop and continuous
  • It can achieve the cuting and stacking of various shaped parts
  • Dedicated blanking press with high rigidit and precision

Production Line Composition

  • Uncoiler
  • Servo feeding
  • Feeding device
  • Telescopic platform
  • Material head shear
  • Blanking press, telescopic belt
  • Cleaning machine
  • Magnetic stacking
  • Leveling machine
  • Inspection bench
  • Adjusting ring
  • Configuration:
    High speed shearing machine/flying shear machine/swinging shear machine, can form an uncoiling shear machine (flying shear line, swinging shear line)
