BC-S120 (CT120) 3-Track Thermal Break Aluminum Sliding Window
| Share | |
|---|---|
| Categories | Aluminum Sliding & Lift Windows |
| Brand | BLOSSOM CHEER Door And Window Project Manufacturer |
| Product Specifications | BC-S120 (CT120) |
| Model | BC-110 |
| Product Type | Thermal Break Aluminum Casement Window |
| Frame Depth | 110–115 mm |
| Project Service | ODM / Custom Project Support |
| Sample | Available |
| Production Time | 15-25 Days |
| FOB port | Guangzhou |
| Terms of Payment | L/C, D/A, D/P, Western Union |
Detail Information
Panoramic 3-Track Thermal Break 26mm Slim Sightlines & Panoramic Daylighting The following engineering metrics are extracted from official drawings and cross-referenced with GB/T 7106, AAMA/WDMA 101, ASTM, and EN sliding-window standards to verify the BC-S120's structural, air/water, and acoustic performance.
BC-S120 (CT120)
Sliding Window System
Engineered for Urban Towers, Offices & Resorts
26mm Slim Frame, 60mm Sash Stile & 61mm Interlock Sightlines
Anti-Sway Top Guides, 160kg+ Tandem Rollers & Integrated Screen Track
BC-S120 (CT120) Core Physical & Structural Specification Matrix
Engineering Metric
Performance Value
Reference Standards
Frame Depth
120 mm modular three-track thermal-break frame
GB/T 8478-2020 / AAMA 101
Alloy & Wall Thickness
2.0 mm 6063-T5 high-precision aluminum throughout the main structural profiles
ASTM B221 / EN 755-2
Frame Sightline
26 mm slim visible outer-frame face for increased panoramic glazing area
Minimal architectural facade sightline standard
Sash Stile Sightline
60 mm reinforced sash-stile visible face
Structural-load and daylighting balance system
Interlock Sightline
61 mm slim overlapping interlock face
International panoramic sliding-window standard
Thermal Break Barrier
Multi-chamber PA66GF25 glass-fiber-reinforced nylon strips with an isothermal thermal-break design
GB/T 23615.1 / EN 14024
Standard Glazing
5 mm + 14A + 5 mm double-tempered insulated glass, with Low-E and argon-filled options
Architectural safety insulated-glass standard
Sealing System
Multiple automotive-grade EPDM gaskets combined with high-density siliconized weatherpile
ISO 3934 / ASTM C864
Top Guide Mechanism
Adjustable upper-track anti-sway rollers for sash stabilization, assisted gliding, and reduced wind rattle
High-wind anti-derailment engineering standard
Drainage System
Stepped pressure-equalized drainage outlets with independent gravity-operated wind baffles
Wind-driven-rain water-management standard
Wind Load Resistance
\
GB/T 7106 / ASTM E330
Water Tightness
\
GB/T 7106 / ASTM E331
Air Permeability
\
GB/T 7106 / ASTM E283
Acoustic Sound Insulation
\
GB/T 8485 / ASTM E90
Insect Screen Options
#304 stainless-steel security mesh, high-definition security mesh, or high-transparency nylon mesh
ASTM A555 safety-screen material standard
Top Anti-Sway Guides, Heavy-Duty Rollers & Baffled Drainage Control
BC-S120 integrates adjustable top anti-sway guides, tandem load-distribution rollers, stainless-steel rails, and gravity-operated wind baffles to deliver stable, quiet sliding performance, 160kg+ sash capacity, and reliable stormwater control through more than 100,000 operating cycles. Adjustable polymer guide wheels close the upper-track clearance to stabilize the sash, assist smooth travel, and suppress wind rattle or derailment risk on exposed high-rise facades. Dual-row composite wear-resistant rollers distribute 160kg+ sash loads across stainless-steel running rails for low-effort travel, long service life, and dependable anti-derailment control. Independent one-way baffles let runoff discharge by gravity, then close automatically under reverse wind pressure to block stormwater backflow into the track and interior floor zone. The concealed transmission system supports flush touch latches, embedded crescent locks, and keyed interlocking handles, allowing security and appearance to be coordinated with each project specification.
Top Anti-Sway Guide Wheel Mechanism
Heavy-Duty Tandem Rollers & Stainless Rails
Gravity-Flap Windproof Drainage Baffles
Multi-Brand Minimalist Lockset Compatibility
Recommended Styles
Explore selected designs from our style library for architectural inspiration. Confirm BC-S120 (CT120) sliding window configurations, opening arrangements and dimensions with our team.
Decorative Moulding Wooden Door II
KX-008
Decorative Moulding Wooden Door
KX-007
Synchronised Moulded Wooden Door
F10
Micro Inlay Wooden Door
F13
Flush Wooden Door
PB-001
Available Colors & Finishes
Explore selected color and texture references from our finish library. Confirm coating suitability for the BC-S120 (CT120) sliding window system and the final color with an approved project sample.
Engineered Wood No. 7
BCPF61
Distant Mountain Pavilion No. 20
BCPF60
Distant Mountain Pavilion No. 21
BCPF59
Quiet Growth Rings No. 25
BCPF58
Quiet Growth Rings No. 26
BCPF57
Twilight Mountain Purple No. 23
BCPF56
Qingning Sandalwood No. 27
BCPF55
Qingning Sandalwood No. 28
BCPF54
Anxiang Wood
BCPF53
Ink Shadow Fir
BCPF52
Yueju Walnut
BCPF51
Fengtan Walnut
BCPF50
Derived from its 120mm three-track frame, 2.0mm structural walls, 26mm slim sightline, anti-sway top guides, and baffled drainage, BC-S120 provides contractors and architects with precise configurations for urban balconies, coastal resort rooms, and transparent interior partitions.
Configure track layout, Low-E or tempered insulated glazing, integrated screening, roller capacity, drainage, and finish around opening width, coastal exposure, acoustic targets, and interior design requirements.
High-rise sliding safety begins with track mechanics and water management. Submit project drawings for a 24-hour
wind-displacement check, anti-backflow drainage review, glazing and roller-load verification, and direct engineering budget confirmation.
Access BC-S120 engineering specifications, AutoCAD three-track installation details, anti-sway guide and baffled-drainage nodes, certified laboratory reports, and 24-hour wind-displacement and anti-backflow review support for global developers, EPC contractors, importers, and lead architects.
Micro-Structure Driven Scenario Configuration & Engineering Matrix
BC-S120 (CT120) Scenario Configurations
Urban Balcony, Coastal Resort & Interior Partition Configurations
Verified Project & Laboratory Evidence
B2B Engineering Submittal & Technical Specification Download Hub
BC-S120 (CT120) Panoramic Three-Track Sliding Window Engineering Product Specification Data Sheet
AutoCAD Three-Track Installation, Anti-Sway Guide & Baffled Drainage Detail Drawing Library
BC-S120 Official Physical Performance Laboratory Test Report — Wind Class 8–9 / Air Class 7–8 / Water Class 4–5 (PDF)
