Displays 45-degree cutaways highlighting 128mm depth, 2.2mm walls, 72mm/84mm sashes, 32mm concealed-strip interlocks, and rigid-flexible seals.
Where Buildings Blossom With Confidence
BC-S128 (PS128) Modular Lift-Slide Door System
| Share | |
|---|---|
| Categories | Aluminum Doors |
| Brand | BLOSSOM CHEER Door And Window Project Manufacturer |
| Frame Depth | 128mm |
| Aluminum Profile | 2.2mm wall thickness, 6063-T5 alloy |
| Sash Width | 72mm standard / 84mm reinforced |
| Slim Interlock | 32mm with concealed thermal break strips |
| Maximum Sash Weight | 600kg |
| Glass Thickness | Up to 37mm |
| Operating Modes: | Standard sliding or lift-slide |
| Production Time | 15-25 Days |
| FOB port | Guangzhou |
| Terms of Payment | L/C, D/A, D/P, Western Union |
Detail Information
BC-S128 (PS128) Modular Lift-Slide System: 600kg Load & 32mm Slim Interlock
Engineered on a modular platform, the BC-S128 combines 2.2mm walls, rigid-flexible seals, and 600kg sash loads to deliver expansive views via 32mm slim interlocks.
Visualizes installations in oceanfront penthouses and luxury resorts, accentuating unobstructed glass daylighting and panoramic horizons.
Architectural In-Situ Renderings
Captures 6063-T5 alloy sections, nylon-silicone composite seals, heavy-duty lift-slide bogies, and flush embedded barrier-free sill details.
Macro Mechanical Details
Unique Engineering Highlights
Shared Interior/Exterior Profiles
Platform Material Efficiency
Frame, top track, and bottom sill share identical profile sections, reducing standard inventory parts by 50% to optimize warehouse storage.
32mm Seamless Interlock Aesthetics
Concealed Thermal Barrier
Integrates central thermal-break profiles flush within 32mm interlocks without exposed strips, eliminating thermal bridge risks.
Fully Concealed Grooves & Bolts
Full-Cover Flush Aesthetics
Covered accessory grooves conceal technical mechanisms even when sashes are open, hiding perimeter frame bolts entirely.
BC-S128 (PS128) Core Physical & Structural Specification Matrix
| Core Physical Specifications & Cross-Sectional Dimensions | Officially Measured Engineering Parameters |
|---|---|
| Frame Depth | 128mm modular, versatile frame system depth |
| Wall Thickness | 2.2mm throughout; 6063-T5 ultra-high-precision aluminum alloy |
| Sash Visible Width | 72mm (standard version) / 84mm (reinforced version for oversized sashes) |
| Interlock Width | 32mm ultra-narrow interlock (thermal break strips recessed and concealed) |
| Frame Visible Width | 40mm ultra-narrow outer frame sightline |
| Max Sash Weight | 600kg (maximum load capacity per sash) |
| Glass Pocket Depth | ≤37mm (accommodates extra-thick triple glazing or laminated insulated glass) |
| Thermal Insulation | K≤2.0 W/(m²⋅K) |
| Solar Heat Gain | 0.2<SHGC≤0.3 (blocks summer solar heat radiation) |
| Sound Insulation | Rw≥36dB (when paired with argon-filled laminated insulated glass) |
| Air Permeability | q1=0.75m³/(m⋅h) (Chinese National Standard Class 8) |
| Water Tightness | ΔP≥350Pa−500Pa+ (embedded high-watertightness track) |
| Wind Load Resistance | ≤5.0kPa (Chinese National Standard Class 9 / withstands Force 14 typhoons) |
| Material Efficiency | Identical profile sections for the top and bottom tracks and the inner and outer sides of the frame, reducing basic material types by approximately 50% |
| Track Expansion | Standard track X+1; expanded tracks X+N+2N+3N… |
| Corner Sealing | Rigid-flexible coupled seals (high-strength nylon support + elastic silicone deformation) |
Lift-Slide Dual Kinematics, Fully Concealed Hardware & 600kg Drive
Featuring standardized slots, the BC-S128 switches between sliding and lift-slide modes while fully concealing all accessory grooves and bolts.
Sliding & Lift-Slide Dual-Mode Conversion
Standardized hardware slots allow conversion between standard sliding and lift-slide kinematics via minimal modular parts.
Concealed Hardware Design
Outfits fully covered accessory grooves to hide mechanical components during sash operation, concealing perimeter frame bolts entirely.
600kg Heavy-Duty Lift Bogie Assemblies
Integrates certified heavy-duty bogie systems rated for 600kg loads, verified via 100,000 operational cycles for effortless glide.
Rigid-Flexible Coupling Corner Seals
Combines high-strength nylon rigid supports with flexible silicone gaskets for controlled deformation, sealing corner air-leakage paths.
Micro-Structure Driven Scenario Configuration & Engineering Matrix
Providing modular configurations tailored to oceanfront villas, barrier-free corridors, and hurricane zones to streamline architectural specification.
Hotel Bathrooms, Kitchen-Dining Spaces & Office Partition Configurations
Coordinate swing, pivot and linked sliding doors with matching finishes, selected glazing and ceiling-recessed track arrangements.
Submit project drawings to coordinate swing or pivot opening, double or triple top tracks, linked panel layouts, glazing, ceiling fixing and matching door finishes.
