Left: 45° cutaway highlighting 16mm stiles, 45mm sash depth, dual-glazing and laminated safety-glass details, and 27/45/55mm casing sections; Right: 1:1 single-leaf, double-leaf and geometric grille elevation drawings.
Where Buildings Blossom With Confidence
16x45 Aluminum Glass Swing Door
| Share | |
|---|---|
| Categories | Aluminum Doors |
| Brand | BLOSSOM CHEER Door And Window Project Manufacturer |
| Visible Stile Width | 16mm |
| Door Leaf Thickness | 45mm |
| Material | 6063-T5 aluminum alloy |
| Casing Widths | 27mm / 45mm / 55mm |
| Glazing | Dual glazing for 27/45mm casings; single glazing for 55mm casing |
| Hinges | Heavy-duty micro-gap hinges |
| Locking | Quiet magnetic lockset |
| FOB port | Guangzhou |
| Terms of Payment | L/C, D/A, D/P, Western Union |
Detail Information
16mm Rigid Glass Swing Door
Designed for executive offices, meeting rooms and luxury bathrooms, this 16x45 system combines 16mm load-bearing stiles, 45mm sash depth and all-aluminum casings in 27mm, 45mm or 55mm widths. The 27mm and 45mm versions support insulated or wired dual glazing for acoustic privacy; the 55mm version uses a wide single-glazing rebate.
Rendered into office meeting rooms with 27mm casings and ultra-clear reeded glass, luxury hotel bathrooms with 45mm casings and gold-diamond glass, and marble-clad corridors with 55mm casings and metal-wired glass.
Commercial & Hospitality
Captures 16mm dual-glazed stiles, inner and outer glass clips, adjustable snap-in casing plates, heavy micro-gap hinges, magnetic locks and the 71.9mm outer frame detail of the 55mm casing version.
Rigid Profiles
Other Highlights of This Product
8 Wired & 15 Embossed Glass Options
The glazing rebates support 8 metal-wired and 15 embossed gold-diamond glass designs in the catalogue, including wired glass 01–08, ultra-clear large and small reeded glass, ultra-clear crystal, double-sided gold-diamond oil-sand, pear and silver-haze glass, with options for different privacy and light-transmission needs.
German-Imported CNC Precision Machining
Profile cutting and corner-key assembly use German-imported precision equipment to create flush, tight mitre joints and maintain the long-term geometric squareness of the sash with its 16mm rigid stile cross-section.
Core Specifications & Tri-Casing Differential Matrix
Data extracted directly from factory blueprints, sharing 16mm load-bearing stiles and 45mm sash depth with 27mm, 45mm and 55mm casing options for different wall openings.
Unified Baseline Specifications
| Metric | Specification Value |
|---|---|
| Door Stile Visible Face Width | 16mm load-bearing stile visible face |
| Door Leaf Structural Thickness | 45mm industrial-grade structural depth |
| Profile Material & Surface Finish | High-durability 6063-T5 aluminum alloy with an internationally advanced coating process |
| Main Load-Bearing Profile Wall Thickness | Estimated: 2.0–2.2mm |
| Hardware Load Capacity per Leaf | Estimated: 50–60kg |
| Moisture & Mold Resistance | All-aluminum body: 100% waterproof, moisture-proof, mold-proof and corrosion-resistant |
| Hardware & Lockset System | Standard heavy-duty micro-gap hinges with a minimalist magnetic silent lockset |
| Series Options | 16x45 Swing Door Series with 27mm, 45mm or 55mm double casings |
| Double-Casing Exposed Widths | 27mm / 45mm / 55mm |
| Outer Frame Depths | 58mm / 65mm / 71.9mm, corresponding to the 27mm / 45mm / 55mm casing versions |
16x45 Swing Door Series: 27mm, 45mm & 55mm Casing Comparison
| Metric | 16x45 Swing Door Series (27mm Casing) | 16x45 Swing Door Series (45mm Casing) | 16x45 Swing Door Series (55mm Casing) |
|---|---|---|---|
| Door Stile Visible Face Width | 16mm load-bearing stile | 16mm load-bearing stile | 16mm load-bearing stile |
| Door Leaf Thickness | 45mm structural thickness | 45mm structural thickness | 45mm structural thickness |
| Hardware & Lockset | Micro-gap hinges + magnetic lock | Micro-gap hinges + magnetic lock | Micro-gap hinges + magnetic lock |
| Casing Exterior Trim Width | 27mm ultra-slim double casing | 45mm classic double casing | 55mm wide double casing |
| Glass Rebate Assembly | Dual-glazed stile supporting insulated or wired glass | Dual-glazed stile supporting insulated or wired glass | Single-glazed stile with a wide single-layer rebate |
| Outer Frame Structural Depth | 58mm installation depth | 65mm installation depth | 71.9mm deepened installation depth |
| Wall Opening Compatibility | Light-steel stud drywall and thin partition walls | Conventional 100–200mm solid brick walls | Extra-thick solid brick walls and marble-clad walls |
| Recommended Applications | Office meeting rooms and minimalist walk-in closets | Standard hotel guest-room bathrooms and apartment master suites | Heavy-duty public-building corridors and marble-clad luxury washrooms |
Heavy Micro-Gap Hinges, Dual-Glass Mechanics & Magnetic Locks
The 16x45 system combines heavy micro-gap hinges and magnetic locksets for smooth operation and close-fitting alignment. Hardware capacity is estimated at 50–60kg per leaf; dual-glazed structural details apply to the 27mm and 45mm casing versions.
Heavy Micro-Gap Hinges — Load Capacity & Precision Gap
Wide, thick hinge plates anchor into reinforcing ribs inside the 45mm sash stile to support dual-glazed panels and resist sagging. Estimated hardware capacity: 50–60kg per leaf. Inferred operating clearance: 1.5–2.0mm.
Magnetic Flush Locksets — Silent Operation
A minimalist handle operates the magnetic lockset. The latch remains flush when open and engages automatically as the door closes, avoiding the metal impact noise of a conventional mechanical latch.
Dual-Glazed Stile Torsional Mechanics
In the 27mm and 45mm casing versions, independent reinforcing ribs and the clamping of inner and outer glass form a composite box structure. Bending and torsional strength increase by over 35% compared with single-glazed stiles.
Micro-Structure Driven Scenario Configuration & Engineering Matrix
Providing modular configurations tailored to oceanfront villas, barrier-free corridors, and hurricane zones to streamline architectural specification.
Hotel Bathrooms, Kitchen-Dining Spaces & Office Partition Configurations
Coordinate swing, pivot and linked sliding doors with matching finishes, selected glazing and ceiling-recessed track arrangements.
Submit project drawings to coordinate swing or pivot opening, double or triple top tracks, linked panel layouts, glazing, ceiling fixing and matching door finishes.
Project & Technical References
Recommended Styles
Explore aluminum-wood door designs from our style library. Confirm the panel finish, frame configuration and dimensions for your project.
Flush Aluminum-Wood Door with HPL Finish — HBD007
HBD007
Concealed Aluminum-Wood Door with HPL Finish
BC2340
Flush Aluminum-Wood Door with HPL Finish
HBD004
Available Colors & Finishes
All wood grain finishes are bonded to the aluminum profile surface via vacuum heat transfer or PUR hot-melt lamination, ensuring zero batch-to-batch color deviation between metal frames and wooden door panels. For overseas projects, international RAL/NCS color cards are available for customized color matching.
Premium No. 14
BCAW20
Premium No. 15
BCAW19
Premium No. 16
BCAW18
Premium No. 11
BCAW17
Premium No. 12
BCAW16
Premium No. 13
BCAW15
Premium No. 18
BCAW14
Premium No. 10
BCAW13
Premium No. 17
BCAW12
Premium No. 2
BCAW11
Premium No. 3
BCAW10
Premium No. 9
BCAW09
